Comprehensive ArgoCD Setup Guide for Kubernetes

Prerequisites

• Kubernetes cluster (v1.19+)
• kubectl CLI tool installed
• Helm (optional)
• Access to a Git repository
• Basic understanding of Kubernetes and GitOps

Step 1: Install ArgoCD

1.1 Create Namespace

apiVersion: v1
kind: Namespace
metadata:
  name: argocd

1.2 Install ArgoCD Core Components

kubectl apply -n argocd -f https://raw.githubusercontent.com/argoproj/argo-cd/stable/manifests/install.yaml

1.3 Verify Installation

kubectl get pods -n argocd

Expected output:

NAME                                  READY   STATUS    RESTARTS   AGE
argocd-application-controller-0       1/1     Running   0          2m
argocd-dex-server-5dd657bd9-xm6x4    1/1     Running   0          2m
argocd-redis-759b6bc7f4-r2qzb        1/1     Running   0          2m
argocd-repo-server-7c475dcc7-nf85p   1/1     Running   0          2m
argocd-server-544c4c6b5-p4h9r        1/1     Running   0          2m

Step 2: Access ArgoCD UI

2.1 Get Initial Admin Password

kubectl -n argocd get secret argocd-initial-admin-secret -o jsonpath="{.data.password}" | base64 -d

2.2 Access the UI

Option 1: Port Forwarding

kubectl port-forward svc/argocd-server -n argocd 8080:443

Option 2: LoadBalancer Service

apiVersion: v1
kind: Service
metadata:
  name: argocd-server
  namespace: argocd
spec:
  type: LoadBalancer
  ports:
    - port: 443
      targetPort: 8080
  selector:
    app.kubernetes.io/name: argocd-server

Step 3: Configure SSO (Optional)

3.1 Setup Dex Configuration

apiVersion: v1
kind: ConfigMap
metadata:
  name: argocd-cm
  namespace: argocd
  labels:
    app.kubernetes.io/name: argocd-cm
    app.kubernetes.io/part-of: argocd
data:
  url: https://argocd.example.com
  dex.config: |
    connectors:
      - type: github
        id: github
        name: GitHub
        config:
          clientID: your-client-id
          clientSecret: your-client-secret
          orgs:
          - name: your-github-org

3.2 Configure RBAC

apiVersion: v1
kind: ConfigMap
metadata:
  name: argocd-rbac-cm
  namespace: argocd
data:
  policy.default: role:readonly
  policy.csv: |
    p, role:org-admin, applications, *, */*, allow
    p, role:org-admin, clusters, get, *, allow
    g, your-github-org:team-name, role:org-admin

Step 4: Setup Your First Application

4.1 Create Application Manifest

apiVersion: argoproj.io/v1alpha1
kind: Application
metadata:
  name: guestbook
  namespace: argocd
spec:
  project: default
  source:
    repoURL: https://github.com/argoproj/argocd-example-apps.git
    targetRevision: HEAD
    path: guestbook
  destination:
    server: https://kubernetes.default.svc
    namespace: guestbook
  syncPolicy:
    automated:
      prune: true
      selfHeal: true
    syncOptions:
      - CreateNamespace=true

4.2 Apply the Application

kubectl apply -f application.yaml

Step 5: Configure High Availability

5.1 HA Manifest

apiVersion: apps/v1
kind: StatefulSet
metadata:
  name: argocd-application-controller
  namespace: argocd # ✅ Added namespace
spec:
  serviceName: "argocd-application-controller" # ✅ Required field
  selector: # ✅ Required field
    matchLabels:
      app: argocd-application-controller
  replicas: 3
  template:
    metadata:
      labels:
        app: argocd-application-controller
    spec:
      containers:
        - name: argocd-application-controller
          args:
            - --status-processors=20
            - --operation-processors=10

5.2.1 Option 1: Delete & Recreate (Recommended)

If you can afford downtime or the StatefulSet doesn’t have critical persistent data:

kubectl delete sts argocd-application-controller -n argocd
kubectl apply -f application-controller.yaml

This option may result in data loss if the StatefulSet has critical persistent data.
Note: Deleting a StatefulSet does not delete associated PVCs unless explicitly specified.

If you want to delete the PVCs too:

kubectl delete pvc -l app=argocd-application-controller -n argocd
kubectl apply -f application-controller.yaml

5.2.2 Option 2: Modify Allowed Fields (No Downtime)

If you only need to change replicas, template, updateStrategy, or minReadySeconds, use kubectl patch instead of applying a new manifest.

kubectl patch statefulset argocd-application-controller -n argocd --type='strategic' -p '{"spec":{"replicas":5}}'

5.2 Resource Requirements

apiVersion: apps/v1
kind: Deployment
metadata:
  name: argocd-server
spec:
  template:
    spec:
      containers:
        - name: argocd-server
          resources:
            requests:
              cpu: 500m
              memory: 512Mi
            limits:
              cpu: 1000m
              memory: 1024Mi

Step 6: Setup Monitoring

6.1 ServiceMonitor Configuration

apiVersion: monitoring.coreos.com/v1
kind: ServiceMonitor
metadata:
  name: argocd-metrics
  namespace: argocd
spec:
  selector:
    matchLabels:
      app.kubernetes.io/name: argocd-server # ✅ Match this with the actual service labels
  namespaceSelector:
    matchNames:
      - argocd # ✅ Ensure Prometheus can scrape from this namespace
  endpoints:
    - port: metrics # ✅ Ensure the service has this port name
      interval: 30s # Optional: Set a scrape interval
      path: /metrics # Optional: Define the metrics path (default is usually `/metrics`)

Make sure to replace `argocd-server` with the actual name of the ArgoCD server service.
Check that the ArgoCD Service exposing metrics has the correct labels and port:

6.2 Grafana Dashboard

apiVersion: v1
kind: ConfigMap
metadata:
  name: argocd-grafana-dashboard
  namespace: monitoring
data:
  argocd-dashboard.json: |
    {
      "title": "ArgoCD Dashboard",
      "panels": [
        {
          "title": "Sync Status",
          "type": "graph"
        },
        {
          "title": "Application Health",
          "type": "graph"
        }
      ]
    }

Step 7: Configure Notifications

7.1 Setup Notification Controller

apiVersion: v1
kind: Secret
metadata:
  name: argocd-notifications-secret
  namespace: argocd
stringData:
  slack-token: "xoxb-your-token"
---
apiVersion: v1
kind: ConfigMap
metadata:
  name: argocd-notifications-cm
  namespace: argocd
data:
  service.slack: |
    token: $slack-token
  trigger.on-sync-status-changed: |
    - when: app.status.sync.status == 'Synced'
      send: [app-sync-succeeded]
    - when: app.status.sync.status == 'OutOfSync'
      send: [app-out-of-sync]

Step 8: Backup Configuration

8.1 Backup CronJob

apiVersion: batch/v1
kind: CronJob
metadata:
  name: argocd-backup
  namespace: argocd
spec:
  schedule: "0 0 * * *"
  jobTemplate:
    spec:
      template:
        spec:
          containers:
            - name: argocd-backup
              image: bitnami/kubectl
              command:
                - /bin/sh
                - -c
                - |
                  kubectl get applications.argoproj.io -n argocd -o yaml > /backup/applications.yaml
                  kubectl get appprojects.argoproj.io -n argocd -o yaml > /backup/projects.yaml

Best Practices Checklist

1. ✅ Use declarative application definitions
2. ✅ Enable automated sync
3. ✅ Configure SSO
4. ✅ Setup RBAC
5. ✅ Enable monitoring
6. ✅ Configure notifications
7. ✅ Regular backups
8. ✅ Resource limits
9. ✅ High availability
10. ✅ Security hardening

Security Considerations

1. TLS Configuration

apiVersion: v1
kind: Secret
metadata:
  name: argocd-secret
  namespace: argocd
type: Opaque
data:
  tls.crt: <base64-encoded-certificate>
  tls.key: <base64-encoded-key>

2. Network Policies

apiVersion: networking.k8s.io/v1
kind: NetworkPolicy
metadata:
  name: argocd-server-network-policy
  namespace: argocd
spec:
  podSelector:
    matchLabels:
      app.kubernetes.io/name: argocd-server
  policyTypes:
    - Ingress
  ingress:
    - from:
        - namespaceSelector:
            matchLabels:
              name: ingress-nginx
      ports:
        - protocol: TCP
          port: 8080

Troubleshooting Guide

Common Issues and Solutions

1. Application Not Syncing

   • Check application logs
   • Verify Git credentials
   • Check network connectivity

2. UI Not Accessible

   • Verify service status
   • Check ingress configuration
   • Validate TLS certificates

3. Authentication Issues

   • Verify SSO configuration
   • Check RBAC settings
   • Validate user permissions

Conclusion

Following this guide will help you set up a production-ready ArgoCD installation. Remember to regularly update ArgoCD and follow security best practices.
